Transformer Radiator RFQ Form

Specialty Transformer Components, LLC
525 McClurg Road
Youngstown, Ohio, 44512
(330) 4727-3000

  Fill out the form below and click 'Submit' to request a quote, or download a PDF of this form here, fill it out and use this form to upload it:

CUSTOMER INFO:


Name (First, Last):
* *

Company:


Phone:


Email:
*

Email Confirm:
*


TRANSFORMER INFO:


Manufacturer:


Date of Manufacture:


Transformer Rating:
MVA

Number of Radiators:



RADIATOR INFO:


QTY:


When Needed:



Mounting Type:
Welded
Bolt-On
Not Sure



Radiator Material:
Cold Rolled Steel 1.0mm (0.039in)
Cold Rolled Steel 1.2mm (0.047in)
Stainless Steel 304L
Stainless Steel 316L



Surface Treatment - External Coating:
Hot Dip Galvanizing
Painting
Hot Dip Galvanizing + Paint
Other (Specify)



Paint Color:



Flange Type:
Rectangular/Square
Round
Not Sure


Radiator Dimensions


A Center Distance:
(600mm-4500mm)(23.6"-177")

B Number of Panels:
(3 to 42)

C Header Pipe Extension:
(mm or in)

D Header Pipe Internal Diameter:
(in)

E Panel Width:
(mm or in)

F Panel Spacing:
(mm or in)


SQUARE FLANGE INFO:


I Square Flange Height:
(mm or in)

J Square Flange Bolt Hole Dimension Center to Center Vertical:
(mm or in)

K Square Flange Width:
(mm or in)

L Square Flange Bolt Hole Dimension Center to Center Horizontal:
(mm or in)

M Square Flange Bolt Hole Diameter:
(mm or in)

N Inside Square Flange Diameter:
(mm or in)


ROUND FLANGE INFO:


P Number of Bolt Holes:


Q Bolt Hole Diameter:
(mm or in)

R Bolt Hole Circle Diameter Thru Centers:
(mm or in)

S Inside Round Flange Diameter:
(mm or in)

T Outside Round Flange Diameter:
(mm or in)

  ***Please enter as much information as you can. All of the above information may not be necessary to provide a preliminary proposal. The factory would be in touch if they need additional information.
